Maszyna do formowania tiksowego
Created with Pixso.

Energy Saving Thixomolding Machine 100MPa 1500 KN Small Injection Molding Machine

Energy Saving Thixomolding Machine 100MPa 1500 KN Small Injection Molding Machine

Nazwa marki: EMT
MOQ: Do negocjacji
Cena £: negotiable
Warunki płatności: T/T, Western Union
Zdolność do zaopatrzenia: 50000 sztuk / miesiąc
Szczegółowe informacje
Miejsce pochodzenia:
CHINY
Orzecznictwo:
TS16949、IOS9001
Operacyjny:
Bezpieczeństwo
Materiał:
Ze stopu magnezu
Zdolność produkcyjna:
wysoki
Wymiary:
Klient wymagany
Oszczędzanie energii:
TAK
Prędkość wtrysku:
szybki
Szczegóły pakowania:
Zgodnie z potrzebami klienta
Możliwość Supply:
50000 sztuk / miesiąc
Podkreślić:

Energy saving Thixomolding Machine

,

100MPa Thixomolding Machine

,

1500 KN small injection molding machine

Opis produktu

Energy Saving Thixomolding Machine 100MPa 1500 KN Small Injection Molding Machine

Mg-1500 magnesium alloy semi-solid injection molding machine

Technical parameters



No.DescriptionUnitMG-1500
I. Mold locking
1Mold locking forcekN15000
2Mold lock strokemm1200
3Mold thickness (minimum to maximum)mm500-1400
4Clamping plate dimension (horizontal × vertical)mm2010x1960
5Column spacing (horizontal × vertical)mm1180×1180
6Way of mold installation T-groove way
II. Injection
1Screw diametermm130
2Injection pressureMPa100
3Theoretical injection volumecm³4635
4Theoretical injection massg6675
5Theoretical injection ratecm³∕s61055
6Screw’s maximum injection speedm∕s5
7Screw’s rotation speedr∕min10-285
8Injection strokemm350
9Injection nozzle dimensionmmφ25×R45
10Injection nozzle inletmm75
11Injection nozzle contact forcekN800
12Injection device positionmm0,-350
I. Others
1Systematic operating pressureMPa16
2Ejection forcekN570
3Ejection strokemm250
4Electric motor powerkW45×2
5Heater’s output powerkW120
6Melting servo motor powerkW80
7Total electric capacitykW260
8Oil tank capacityL1500
9Machine weightkg110000
10Machine’s overall dimension (L×W×H)m14x6.4x4.5



Product Advantage:
Magnesium alloy is a high-performance lightweight structural material made of magnesium. Its specific gravity is similar to that of plastic, and its stiffness and strength is no less than that of aluminum. It has strong seismic, electromagnetic, thermal and electrical properties, and can be completely recycled and pollution-free. Magnesium light quality, its density is only 1.7 kg/m3, is two-thirds of aluminum, steel, about a quarter of the strength higher than that of aluminum alloy and steel, than the stiffness is close to aluminum alloy and steel, able to withstand a certain load, good castability and dimensional stability, easy processing, low rejection rate, good damping coefficient, damping quantity is greater than the aluminum alloy and cast iron, It is very suitable for automobile production, and has a wide application space in aerospace, portable computers, mobile phones, electrical appliances, sports equipment and other fields.
Energy Saving Thixomolding Machine 100MPa 1500 KN Small Injection Molding Machine 0
Energy Saving Thixomolding Machine 100MPa 1500 KN Small Injection Molding Machine 1
Energy Saving Thixomolding Machine 100MPa 1500 KN Small Injection Molding Machine 2
Advantage:
Energy Saving Thixomolding Machine 100MPa 1500 KN Small Injection Molding Machine 3

FAQ:
1. Q:Are you a factory or a trading company?
A:We are a factory which has been focus on Magnesium alloy deep processing lightweight field & semi-solid injection molding of Magnesium alloy for more than 16+ years.
2. Q: Is there quality control on all production lines?
A: Yes, all production lines have adequate quality control.
3. Q: Has the company established and implemented a standard procedure for purchasing contract review and approval?
A: Yes, with written standard procedures.
4. Q: Is there a procedure to conduct random product inspections after final packaging?
A: Yes, with clear standard and written inspection records.
5. Q: How can I get a quotation?
A: Please kindly send us following information 1) Product drawings by STEP/STP/PRT/PDF/IGS format etc. 2) Material, size and surface treatment request. 3) Required quantity. Normally,the quote will be offer in 1-6 hours. :)
6. Q: What is your payment terms?
A: T/T, Western Union, etc.
